Schalten
FS105D 5.0
Planung
1 3

5-Port 10/100 Mbps Desktop Switch

5-Port 10/100 Mbps Desktop Switch, FS105D 5.0

FS105D 5.0

A 5-FE switch with USB-C power input designed for wired network expansion in home and office environments.

  • 5× Fast-Ethernet-Ports
  • Stromversorgung über USB-C
  • Desktop, Wandmontage
  • 88×52,5×24 mm (3,46×2,07×0,94″)
  • 49 g (1,73 Unzen)
Vollständige Details anzeigen
Modellversion
Modellversion FS105D 5.0
Interfaces
Interfaces 10/100 Mbps RJ45 Ports 5
LED
  • Power
  • Link/ACT of Each Ethernet Port
Power Interfaces USB-C Port
Performance
Performance Copper Speed and Distance
  • Cat. 3 or higher cable: 100 meters at 10 Mbps
  • Cat. 5 or higher cable: 100 meters at 100 Mbps
MAC Address Table 2048
Max Switching Capacity 1 Gbps
Max Forwarding Rate 0.744 Mpps
Packet Buffer 570 Kbit
Power
Power Basic Power Saving True
Power Methods USB-C
Power Input 5V⎓1A
Max Power Consumption 0.5W
Idle Power Consumption 0.32W
Switching
Switching 802.3 Protocols
  • 802.3i 10BASE-T
  • 802.3u 100BASE-TX
Reliability
Reliability Environment Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 75 ℃ (-40 ℉ ~ 167 ℉)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
Mechanical
Mechanical Dimension 88×52.5×24 mm
3.46×2.07×0.94 inches
Casing Material Plastic
Installation
  • Desktop
  • Wall-mount
Package Content
Package Content
  • FS105D
  • USB-A to USB-C Power Cable
  • Installation Guide
