AC1200 千兆網狀 Wi-Fi 路由器,WR1300 3.0

AC1200 千兆網狀 Wi-Fi 路由器,WR1300 3.0

WR1300 3.0

雙頻 AC1200 WiFi 路由器非常適合流暢的 4K 播放、遊戲、連接到最大 1000 Mbps 的互聯網接入,具有 Cudy Mesh、應用程式控制、VPN 和 MU-MIMO。


  • 4 筆資料流雙頻 Wi-Fi 5
  • 867 Mbps + 300 Mbps 無線網絡 1
  • 5 個千兆乙太網路埠
  • 4× 高增益天線
  • 50 個連接設備 2
  • 佔地 100 平方米(1,100 平方英尺) 3
  • Cudy Mesh、VPN 伺服器和用戶端
  • Cudy App、雲端控制
查看完整資訊
硬體規格
軟體規格
型號版本
型號版本 WR1300 3.0
CPU
CPU Chipset MT7621
CPU Details 880 MHz Dual-Core, MIPS1004Kc
Memory/Storage
Memory/Storage Flash/ROM 16 MB (128 Mbit) NOR
DDR/RAM 128 MB (1 Gbit) DDR3
Wireless
Wireless 5 GHz Wi-Fi Speed 867 Mbps
2.4 GHz Wi-Fi Speed 300 Mbps
5 GHz Wi-Fi Streams 2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams 2T2R (2×2 MIMO)
Wi-Fi Antennas 4× Fixed
5 GHz Antenna Gain Max 5dBi
2.4 GHz Antenna Gain Max 5dBi
FEM or PA/LNA
  • 5 GHz: 2× Internal
  • 2.4 GHz: 2× Internal
Beamforming True
Range Performance Max: 170 m (558 ft)
Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
Wall Performance One wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'')
Interfaces
Interfaces Gigabit RJ45 Ports 5
Ethernet Notes 1× WAN port, the rest are LAN ports
LED
  • Power
  • 2.4 GHz Wi-Fi
  • 5 GHz Wi-Fi
  • WPS
  • Speed/Link/ACT of Ethernet Port
Physical Buttons
  • WPS Button
  • Reset Button
Power Input DC Jack
Power
Power Power Methods DC
DC 12V 1A
Power Adapter Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC
Max Power Consumption (W) 9.27W
Idle Power Consumption (W) 3.56W
Reliability
Reliability Environment
  • Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
  • Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
  • Humidity: 10% ~ 90% non-condensing
  • Storage Humidity: 5% ~ 95% non-condensing
Certifications
Certifications FCC, CE
Mechanical
Mechanical Installation
  • Desktop
  • Wall-mount
Dimension 204.8×137.5×38.3 mm
8.06×5.41×1.51 inches
Product Weight
  • EU / US: 319 g (11.25 oz.)
  • ZH: 318.4 g (11.23 oz.)
Package Content
Package Content
  • WR1300
  • Power Adapter
  • Ethernet Cable
  • Installation Guide
Ordering Information
Ordering Information Retail Package Weight
  • BR: 716 g (25.26 oz.)
  • EU / US: 727 g (25.64 oz.)
  • ZH: 666.4 g (23.51 oz.)
Retail Package Dimension 280×278×56 mm
11.02×10.94×2.2 inches
Units per Carton 20
Carton Dimension 59×58×30.3 cm
23.23×22.83×11.93 inches
Carton Gross Weight
  • BR: 15.7 kg (34.61 lbs)
  • EU / US: 16.2 kg (35.71 lbs)
  • ZH: 14.7 kg (32.41 lbs)
Carton Net Weight
  • BR: 14.3 kg (31.53 lbs)
  • EU / US: 14.5 kg (31.97 lbs)
  • ZH: 13.3 kg (29.32 lbs)
型號版本
型號版本 WR1300 3.0
Wireless
Wireless Wi-Fi Standards Wi-Fi 5
Max Wi-Fi Modulation 256-QAM
Wi-Fi Efficiency MU-MIMO
Wi-Fi Efficiency Note MU-MIMO available on 5 GHz
Max Capacity 128
Recommended Client Upper Limit 50
Max Wi-Fi Channel Width 80 MHz
Wi-Fi Security WPA/WPA2/WPA3
Guest Network 2.4 GHz, 5 GHz
WPS True
General
General Operation Modes
  • Wi-Fi Router
  • Access Point
  • Range Extender
  • WISP
  • Client
Mesh Cudy Mesh
Mesh Backhaul
  • Wireless Backhaul
  • Wired Backhaul
Multi-Band Backhaul true
WAN Mode
  • DHCP
  • Static IP
  • PPPOE
  • PPTP
  • L2TP
Internet Failover Sequence
  • WAN
  • WISP
Network
Network QoS Per-User Rate Limiting
DHCP
  • Address Reservation
  • DHCP Client List
  • Server
IP Versions IPv4/IPv6
IPv6 Protocols
  • Relay
  • Dynamic (SLAAC/DHCPv6)
  • Staic (Fixed IP)
  • Passthrough
  • 464XLAT
  • MAP-E
  • DS-Lite
IPTV/VLAN
  • Bridge
  • Tag VLAN
TTL Customization
  • Extend
  • Spoof
  • Custom
IGMP
  • IGMP Proxy
  • IGMP Snooping
Forwarding
  • Port Forwarding
  • Port Triggering
  • UPnP
  • DMZ
Firewall
  • SPI Firewall
  • DoS Protection
  • Block PING
Application Layer Gateway
  • IPSec Passthrough
  • L2TP Passthrough
  • PPTP Passthrough
  • FTP Passthrough
  • TFTP Passthrough
  • H323 Passthrough
  • SIP Passthrough
  • RTSP Passthrough
Utilities
Utilities VPN Server
  • WireGuard
  • OpenVPN
  • IPsec
  • Zerotier
  • PPTP
  • L2TP
VPN Client
  • WireGuard
  • OpenVPN
  • IPsec
  • Zerotier
  • PPTP
  • L2TP
VPN Performance
  • OpenVPN Client (UL/DL): 22 / 24.7 Mbps
  • OpenVPN Server (UL/DL): 22 / 20.9 Mbps
  • WireGuard Client (UL/DL): 142 / 233.9 Mbps
  • WireGuard Server (UL/DL): 213 / 152 Mbps
DNS Options
  • DNS over TLS
  • Manual DNS
  • Rebind Protection
  • Override Clients' DNS
DNS over TLS Providers
  • Cloudflare
  • Google
  • Quad9
  • Custom
Captive Portal True
Wake on LAN True
Online Detection True
Max Concurrent VPN Tunnels
  • IPSec: 20
  • PPTP/L2TP: 16
  • OpenVPN: 16
General
General Max Concurrent Sessions 25000
Management
Management All Devices Management
  • Wi-Fi Time Schedule
  • MAC Filter
  • IP/MAC Binding
Per-Devices Management
  • Intenent On/Off
  • VPN On/Off
  • Online Time Schedule
  • Device Rename
Content Management
  • Domain Filter
  • IP Filter
System
System Local Control Method
  • Config Web Page
  • App Control
Remote Control Method
  • Config Page via HTTPS
  • App Control
  • TR069/TR098/TR111/TR181
Firmware Upgrade
  • Local Update
  • App (Over the Air)
  • Online Update
Reliability
  • Timed Reboot
  • Backup and Restore
Diagnostic Tools
  • Diagnosis
  • Ping
  • Traceroute
  • NSLookup
  • System Log
Languages
  • English
  • Bengali
  • Catalan
  • Czech
  • German
  • Greek
  • Spanish
  • French
  • Hebrew
  • Croatian
  • Hungarian
  • Italian
  • Japanese
  • Khmer
  • Korean
  • Dutch
  • Norwegian
  • Polish
  • Portuguese
  • Romanian
  • Russian
  • Slovak
  • Swedish
  • Thai
  • Turkish
  • Ukrainian
  • Vietnamese
  • Simplified Chinese
  • Traditional Chinese
Dashboard
Dashboard Panel
  • Internet Status
  • Mesh Status
  • Devices Management
  • WAN Status
  • LAN Status
  • WISP Status
  • Wi-Fi Status
  • VPN Status
  • DHCP Server Status
  • System Version
Charts
  • Mesh Topology
  • Internet Speed
  • WISP Speed
  • Wi-Fi Speed

  1. 實際無線資料吞吐量會因網路條件、客戶端限制和環境因素(包括建築佈局、障礙物和客戶端位置)而有所不同。
  2. 多個設備的實際性能可能會受到所使用的應用程式類型、總可用頻寬和設備功能的影響。連接較舊的 Wi-Fi 設備(舊標準)可能會降低整體效率。使用效率功能需要也支援這些功能的相容客戶端設備。在規格電子表格的軟體部分中尋找有關支援的效率功能的更多資訊。
  3. 無線覆蓋範圍聲明僅供參考。覆蓋性能會因環境因素(包括建築佈局、障礙物、交通量和密度以及設備位置)而有所不同。為了獲得最佳覆蓋範圍,請將裝置放置在需要 Wi-Fi 的區域的中心位置。
