工作、娛樂和充電——同時進行
以 5 Gbps 的速度連接 USB 週邊設備
一次連接，即可獲得電源和數據
| 型號版本 | ||
|---|---|---|
| 型號版本 | UH606 1.0 | |
| Interfaces | ||
| Interfaces | Upstream Connection | 1× USB-C 3.2 Gen 1 Male Connector (5 Gbps) |
| Video Output | 1× HDMI 2.0 | |
| Video Output Resolutions |
|
|
| Video Output Modes |
Extend, Mirror Android phone supports mirror mode only |
|
| USB Ports | 3× USB-A 3.2 Gen 1 Ports (5 Gbps) | |
| Network | 1× Gigabit RJ45 Port | |
| Network Feature | Wake on LAN | |
| Power Input | USB-C Port | |
| Power | ||
| Power | Power Methods | DC / PD |
| DC | 5~20V 0~5A | |
| Max Power Consumption (W) |
100W if powered by a PD Adapter 10W if powered by the host client's USB Power |
|
| Idle Power Consumption (W) | 0.4W | |
| Physical | ||
| Physical | Color | Silver Gray Color |
| Casing |
|
|
| Requirements | ||
| Requirements | Hardware Requirement | Requires a USB-C 3.2 Gen 1 / USB4 / Thunderbolt 3/4 port on the host device |
| Compatible OS |
|
|
| Driver Installation |
Auto driver installation for Windows 10/11 PC, Macs with M chipset. Manual driver installation may required on other platform. |
|
| Reliability | ||
| Reliability | Environment |
|
| Mechanical | ||
| Mechanical | Product Weight | 78.2 g (2.76 oz.) |
| Dimension |
Main Part : 113.1×44.2×15.7 mm 4.45×1.74×0.62 inches Cable: 200 mm 7.87 inches |
|
| Package Content | ||
| Package Content |
|
|
| Ordering Information | ||
| Ordering Information | Retail Package Weight | 120.4 g (4.25 oz.) |
| Retail Package Dimension |
88.5×163.5×20 mm 3.48×6.44×0.79 inches |
|
| Units per Carton | 200 | |
| Carton Net Weight | 12.1 kg (26.68 lbs) | |
| Carton Gross Weight | 12.9 kg (28.44 lbs) | |
| Carton Dimension |
44×37×30 cm 17.32×14.57×11.81 inches |
|
- 有關支援的作業系統版本，請參閱"規格"部分。
