Built for Every Scenario

Tired of Limited Router Features?

OpenWrt support lets you freely customize your network with plugins for ad blocking, routing, and advanced home setups.

Struggling With Unstable Internet on the Go?

Stay connected with reliable performance for work in airports, hotels, and remote locations.

Worried About Unsafe Public Wi-Fi?

Turn hotel Wi-Fi into a secure, encrypted private connection to protect your data from potential threats.

Tired of Weak or Unstable Outdoor Internet?

Keep multiple devices online with stable performance, even during travel or outdoor activities.

Flexible Internet Access Options

MediaTek 2 GHz Dual-Core CPU

More Power. More Memory.
More Confidence.

Powered by a MediaTek 2 GHz dual-core processor, 512 MB RAM, and 256 MB Flash, it provides the processing power and memory headroom to handle more tasks smoothly, ensuring fast, stable performance even after years of use.

MediaTek 2 GHz Dual-Core CPU

More Power. More Memory.
More Confidence.

Powered by a MediaTek 2 GHz dual-core processor, 512 MB RAM, and 256 MB Flash, it provides the processing power and memory headroom to handle more tasks smoothly, ensuring fast, stable performance even after years of use.

Unlock Your Router's Full Potential

OpenWrt support enables extensive customization, feature expansion, and advanced networking capabilities, giving you complete control over your network.

Unlock Your Router's Full Potential

OpenWrt support enables extensive customization, feature expansion, and advanced networking capabilities, giving you complete control over your network.

Dual 2.5G Ports + USB-C

Fast Networking. Flexible Powering.

Dual 2.5G ports deliver blazing-fast performance for low-latency gaming, high-speed file transfers, and full-speed NAS access. Powered by USB-C, TR3600 works with a phone charger, power bank, or USB adapter, making it easy to deploy at home, in the office, or on the go.

Dual 2.5G Ports + USB-C

Fast Networking. Flexible Powering.

Dual 2.5G ports deliver blazing-fast performance for low-latency gaming, high-speed file transfers, and full-speed NAS access. Powered by USB-C, TR3600 works with a phone charger, power bank, or USB adapter, making it easy to deploy at home, in the office, or on the go.

USB 5V/2A Power Output

Keep Your Portable Wi-Fi Running

With a 5V/2A USB output, TR3600 delivers the stable power portable Wi-Fi devices need, helping prevent disconnects and unexpected reboots caused by insufficient power.

USB 5V/2A Power Output

Keep Your Portable Wi-Fi Running

With a 5V/2A USB output, TR3600 delivers the stable power portable Wi-Fi devices need, helping prevent disconnects and unexpected reboots caused by insufficient power.

USB File Sharing

Turn USB Storage into Your Personal Cloud

Connect a USB drive or external hard drive to instantly create shared storage for every device on your network. With secure remote access enabled, you can reach your files anytime, from anywhere.

USB File Sharing

Turn USB Storage into Your Personal Cloud

Connect a USB drive or external hard drive to instantly create shared storage for every device on your network. With secure remote access enabled, you can reach your files anytime, from anywhere.

Smart Cooling System

Quiet Performance. Stable Speed.

An advanced heatsink design combined with a smart, silent fan ensures efficient heat dissipation. Built-in thermal control automatically adjusts fan speed based on workload, keeping performance stable even under heavy use.

Smart Cooling System

Quiet Performance. Stable Speed.

An advanced heatsink design combined with a smart, silent fan ensures efficient heat dissipation. Built-in thermal control automatically adjusts fan speed based on workload, keeping performance stable even under heavy use.

120+ Devices, No Slowdowns

Handle over 120 connected devices with confidence, keeping streaming, gaming, video calls, and smart home devices running smoothly.

120+ Devices, No Slowdowns

Handle over 120 connected devices with confidence, keeping streaming, gaming, video calls, and smart home devices running smoothly.

1 4

BE3600 2.5G Wi-Fi 7 Seyahat Yönlendiricisi

BE3600 2.5G Wi-Fi 7 Seyahat Yönlendiricisi, TR3600 1.0

TR3600 1.0

Ofisle olan bağlantıları şifrelemek, ücretli Wi-Fi paylaşımı yapmak ve dosya sunucusu barındırmak için ideal, USB-C ile çalışan mini Wi-Fi 7 yönlendirici.

  • MediaTek Çift Çekirdekli A53 CPU
  • 2882 ​​Mbps + 688 Mbps Wi-Fi 1
  • 2 adet 2.5G Ethernet bağlantı noktası
  • 1 adet USB 3.0 bağlantı noktası
  • USB-C üzerinden güç sağlama
  • 160 g (5,64 oz.)
  • Cudy Mesh, VPN Sunucusu ve İstemcisi
  • Akıllı Fan Soğutma
  • Cudy Uygulaması, Bulut Kontrolü
Tüm ayrıntıları görüntüle
Donanım Özellikleri
Yazılım Özellikleri
Model Versiyonu
Model Versiyonu TR3600 1.0
CPU
CPU CPU Details 2.0 GHz Dual-Core, ARM Cortex-A53
Memory/Storage
Memory/Storage Flash/ROM 256 MB (2 Gbit) NAND
DDR/RAM 512 MB (4 Gbit) DDR4
Wireless
Wireless 5 GHz Wi-Fi Speed 2882 Mbps
2.4 GHz Wi-Fi Speed 688 Mbps
5 GHz Wi-Fi Streams 2 Spatial Streams with 3T3R
2.4 GHz Wi-Fi Streams 2 Spatial Streams
Wi-Fi Antennas 2× Fixed, 1× Internal
FEM or PA/LNA
  • 5 GHz: 3× Internal
  • 2.4 GHz: 2× Internal
Beamforming
Range Performance Max: 180 m (591 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
Wall Performance Two wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'')
Interfaces
Interfaces 2.5G RJ45 Ports 2
Ethernet Notes 1× WAN port, 1× LAN port
USB-A 3.0 Ports 1
LED System
Physical Buttons
  • Reset Button
  • Configurable DIP Switch
Power
Power Power Input Type USB-C Port
Power Methods USB-C
Power Input
  • 5V⎓3A
  • 9V⎓2.2A
  • 12V⎓1.6A
  • PD
Max Power Consumption (W) 15w
Idle Power Consumption (W) 3.9w
Reliability
Reliability Environment
  • Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
  • Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
  • Humidity: 10% ~ 90% non-condensing
  • Storage Humidity: 5% ~ 95% non-condensing
Certifications
Certifications FCC, CE
Mechanical
Mechanical Cooling Built-in Fan
Installation Desktop
Dimension Main Part:
118×80×27.5 mm
4.65×3.15×1.08 inches
Package Content
Package Content
  • TR3600
  • Ethernet Cable
  • Power Adapter
  • Installation Guide
Ordering Information
Ordering Information Retail Package Dimension 176×140.5×56 mm
6.93×5.53×2.2 inches
Units per Carton 40
Carton Dimension 60×30×37.5 cm
23.62×11.81×14.76 inches
Model Versiyonu
Model Versiyonu TR3600 1.0
Wireless
Wireless Wi-Fi Standards Wi-Fi 7
Max Wi-Fi Modulation 4K-QAM
Wi-Fi Efficiency
  • MLO
  • MRU
  • Puncturing
  • OFDMA
  • MU-MIMO
  • BSS Color
Max Capacity 256
Recommended Client Upper Limit 120
Wi-Fi Channel Width Auto/20/40/80/160 MHz
Wi-Fi Security WPA/WPA2/WPA3
Guest Network 2.4 GHz, 5 GHz
WPS
General
General Operation Modes
  • Wi-Fi Router
  • Access Point
  • Range Extender
  • WISP
  • Client
Mesh Cudy Mesh
Mesh Backhaul
  • Wireless Backhaul
  • Wired Backhaul
Multi-Band Backhaul
WAN Mode
  • DHCP
  • Static IP
  • PPPOE
  • PPTP
  • L2TP
Network
Network QoS Per-User Rate Limiting
DHCP
  • Address Reservation
  • DHCP Client List
  • Server
IP Versions IPv4/IPv6
IPv6 Protocols
  • Relay
  • Dynamic (SLAAC/DHCPv6)
  • Static (Fixed IP)
  • Passthrough
  • 464XLAT
  • MAP-E
  • DS-Lite
Multicast
TTL Customization
  • Extend
  • Spoof
  • Custom
IGMP
  • IGMP Proxy
  • IGMP Snooping
Forwarding
  • Port Forwarding
  • Port Triggering
  • UPnP
  • DMZ
Firewall
  • SPI Firewall
  • DoS Protection
  • Block PING
Application Layer Gateway
  • IPSec Passthrough
  • L2TP Passthrough
  • PPTP Passthrough
  • FTP Passthrough
  • TFTP Passthrough
  • H323 Passthrough
  • SIP Passthrough
  • RTSP Passthrough
Utilities
Utilities VPN Server
  • WireGuard
  • OpenVPN
  • IPsec
  • Zerotier
  • PPTP
  • L2TP
VPN Client
  • WireGuard
  • OpenVPN
  • IPsec
  • Zerotier
  • PPTP
  • L2TP
VPN Performance
  • OpenVPN Client (UL/DL): 654 / 798 Mbps
  • OpenVPN Server (UL/DL): 558 / 566 Mbps
  • WireGuard Client (UL/DL): 636 / 637 Mbps
  • WireGuard Server (UL/DL): 544 / 644 Mbps
DNS Options
  • DNS over TLS
  • Manual DNS
  • Rebind Protection
  • Override Clients' DNS
DNS over TLS Providers
  • Cloudflare
  • Google
  • Quad9
  • Custom
USB Functions
  • Samba Server
  • Tethering
Wake on LAN
Online Detection
Management
Management Parental Controls
  • Profiles Settings
  • Offline Time
  • Online Time
  • Pause the Internet
  • Web Filter
All Devices Management
  • Wi-Fi Time Schedule
  • MAC Filter
  • IP/MAC Binding
Per-Devices Management
  • Internet On/Off
  • VPN On/Off
  • Online Time Schedule
  • Device Rename
Content Management
  • Domain Filter
  • IP Filter
System
System LED Control
Local Control Method
  • Config Web Page
  • App Control
Remote Control Method
  • Config Page via HTTPS
  • App Control
  • TR069/TR098/TR111/TR143/TR181
Firmware Upgrade
  • Local Update
  • App (Over the Air)
  • Online Update
Reliability
  • Timed Reboot
  • Backup and Restore
Diagnostic Tools
  • Diagnosis
  • Ping
  • Traceroute
  • NSLookup
  • System Log
Languages
  • English
  • Bengali
  • Catalan
  • Czech
  • German
  • Greek
  • Spanish
  • French
  • Hebrew
  • Croatian
  • Hungarian
  • Italian
  • Japanese
  • Khmer
  • Korean
  • Dutch
  • Norwegian
  • Polish
  • Portuguese
  • Romanian
  • Russian
  • Slovak
  • Swedish
  • Thai
  • Turkish
  • Ukrainian
  • Vietnamese
  • Simplified Chinese
  • Traditional Chinese
Dashboard
Dashboard Panel
  • Internet Status
  • Mesh Status
  • Devices Management
  • WAN Status
  • LAN Status
  • WISP Status
  • Wi-Fi Status
  • VPN Status
  • DHCP Server Status
  • System Version
Charts
  • Mesh Topology
  • Internet Speed
  • WISP Speed
  • Wi-Fi Speed
  1. Gerçek kablosuz veri aktarım hızı, ağ koşullarına, istemci sınırlamalarına ve bina düzeni, engeller ve istemci konumu gibi çevresel faktörlere bağlı olarak değişiklik gösterecektir.
