Cudy P5 adopts upgraded 3GPP Rel.16 standard and supports both 5G NSA and SA modes to work with all the mainstream carriers worldwide.

Qualcomm X62 5G modem, enabled by Advanced AI features and a 4nm process chip, provides data downlink speed up to 3.4 Gbps.

Īpaši ātrs Wi-Fi 6

The entire 160 Mhz channel width enables peak speed at 2402 Mbps on the 5 GHz band, which is best for lag-free gaming and live streaming with flawless quality. Far-reaching 2.4 GHz signal covers an expansive area so that you can enjoy the network in the backyard. OFDMA and powerful CPU enable 4× capacity for more devices.

Īpaši ātrs Wi-Fi 6

Divi SIM karšu slots

Dual SIM slots provide redundancy and keep the device always online.

Rezerves un noņemamās antenas

WAN/Cellular1/Cellular2 give you triple backups for a reliable network. To enhance signal quality, you may replace cellular antennas with extension antennas.

Tiešsaistes atlaišana

Dual SIM slot redundance and WAN/Cellular backup provide high redundancy for the network.

Joslas bloķēšana

4G/5G joslas bloķēšana ļauj bloķēt 4G darba frekvenci vienā vai vairākās joslās, lai saglabātu darbības stabilitāti.

(Attēls uzziņai. Skatiet atbalstītās joslas specifikāciju lapā)

TTL iestatījumi

Support manual sets TTL values to meet ISP's requirements. Support set IPv4 TTL and IPv6 HL Values.

Uzlabota DNS drošība

Encrypt your web browsing lookup with trustful partners, preventing eavesdropping and manipulation of DNS data via a man-in-the-middle attack.

VPN serveris un klienti

VPN pieejams vairākos veidos

Connect back to your company or private network in any way you are used to. Or hold a VPN server to build up your private and secure network. LT12 supports all mainstream VPN protocols, including PPTP, L2TP, OpenVPN, WireGuard, IPSec, and ZEROTIER.

VPN serveris un klienti

VPN pieejams vairākos veidos

Cudy lietotne

Manage your network from your phone. This model supports cloud remote control and local control via the Cudy App.

‏‏‎

Learn More

Cudy lietotne

Manage your network from your phone. This model supports cloud remote control and local control via the Cudy App.

‏‏‎

Learn More

NaN -Infinity

5G SA/NSA AX3000 Wi-Fi 6 maršrutētājs

Name: 5G SA/NSA AX3000 Wi-Fi 6 maršrutētājs, P5 1.0
Brand: Cudy

5G SA/NSA AX3000 Wi-Fi 6 maršrutētājs, P5 1.0

P5 1.0

Product variants

5G WiFi 6 maršrutētājs, kas izmanto 3GPP Release 16 standartu ar maksimālo lejupielādes ātrumu 3,4 Gbps. Tas ir aprīkots ar pilnīgiem Qualcomm risinājumiem, diviem SIM karšu slotiem un jaudīgu AX3000 WiFi 6.

5G Rel. 16 with Max 3.4 Gbps DL ¹
UL/DL 4CA, 4×4 ĀRPUSĒ
4 plūsmu divjoslu Wi-Fi 6
2402 Mbps + 574 Mbps Wi-Fi ²
4× Gigabit Ethernet porti
2× Nano SIM slots
Noņemamas mobilo sakaru antenas
Cudy Mesh, VPN serveris un klients
Cury App, mākoņa vadība

View full details

Aparatūras specifikācijas

Programmatūras specifikācijas

Modeļa versija
Modeļa versija	P5 1.0
CPU
CPU	CPU Details	1.0 GHz Dual-core, ARM Cortex-A53
Memory/Storage
Memory/Storage	Flash/ROM	128 MB (1 Gbit) NAND
	DDR/RAM	256 MB (2 Gbit) DDR3
Cellular
Cellular	Cellular Standards	5G Rel. 16 DL 4G Cat. 19 / UL 4G Cat. 18
	Cellular Antennas	4× Detachable
	Detachable Cellular Antennas Connector	SMA Female
	SIM Options	2× Nano SIM Slots
	Available Versions	EU, US
EU Version Cellular
EU Version Cellular	Suitable Region	Europe, Middle East, Africa, Asia-Pacific (Exc. JP, CN), Brazil
	Max DL Speed	3.4 Gbps (NSA), 2.4 Gbps (SA)
	Max UL Speed	550 Mbps (NSA), 900 Mbps (SA)
	Advanced	DL/UL 4CA, DL 4×4, UL 2×2 MIMO
	Cellular Bands	5G Sub 6 GHz: n1/3/5/7/8/20/28/38/40/41/71/75/76/77/78 LTE-FDD: B1/3/5/7/8/20/28/32/71 LTE-TDD: B38/40/41/42/43 WCDMA: B1/5/8
US Version Cellular
US Version Cellular	Suitable Region	Global
	Max DL Speed	3.4 Gbps (NSA), 2.4 Gbps (SA)
	Max UL Speed	550 Mbps (NSA), 900 Mbps (SA)
	Advanced	DL/UL 4CA, DL 4×4, UL 2×2 MIMO
	Cellular Bands	5G Sub 6 GHz: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/71/75/76/77/78/79 LTE-FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71 LTE-TDD: B34/38/39/40/41/42/43/48; LAA: B46 WCDMA: B1/2/4/5/8/19
Wireless
Wireless	5 GHz Wi-Fi Speed	2402 Mbps
	2.4 GHz Wi-Fi Speed	574 Mbps
	5 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
	2.4 GHz Wi-Fi Streams	2T2R (2×2 MIMO)
	Wi-Fi Antennas	2× Fixed
	Beamforming	True
	FEM or PA/LNA	5 GHz: 2× External 2.4 GHz: 2× External
	Range Performance	Max: 170 m (558 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.
	Wall Performance	Two wooden walls with thickness < 10 cm (4'') One concrete wall with thickness < 20 cm (7'')
Interfaces
Interfaces	Physical Buttons	WPS Button Reset Button
	Gigabit RJ45 Ports	4
	Ethernet Notes	1× RJ45 port is WAN/LAN configurable, and the rest are LAN ports
	LED	Power Internet Wi-Fi Cellular
	Power Input	DC Jack
Power
Power	Power Methods	DC
	DC Input	12V 2.5A
	Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 2.5A DC
Reliability
Reliability	EMC	ESD: Contact: 4kV; Air: 8kV
	Environment	Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing
Certifications
Certifications	FCC, CE
Mechanical
Mechanical	Dimension	253×152.5×48.2 mm 9.96×6×1.9 inches
	Product Weight	670 g (23.63 oz.)
	Installation	Desktop Wall-mount
Package Content
Package Content	P5 Detachable Antennas Power Adapter Ethernet Cable Installation Guide
Ordering Information
Ordering Information	Retail Package Weight	US: 1243 g (43.85 oz.) EU: 1231 g (43.42 oz.)
	Retail Package Dimension	393×250×60 mm 15.47×9.84×2.36 inches
	Units per Carton	10
	Carton Net Weight	US: 12.4 kg (27.34 lbs) EU: 12.3 kg (27.12 lbs)
	Carton Gross Weight	US: 13.15 kg (28.99 lbs) EU: 13.3 kg (29.32 lbs)
	Carton Dimension	40.8×33×52.5 cm 16.06×12.99×20.67 inches

Modeļa versija
Modeļa versija	P5 1.0
Wireless
Wireless	Wi-Fi Standards	Wi-Fi 6
	Max Wi-Fi Modulation	1024-QAM
	Wi-Fi Efficiency	OFDMA MU-MIMO BSS Color
	Max Capacity	256
	Recommended Client Upper Limit	100
	Max Wi-Fi Channel Width	160 MHz
	Wi-Fi Security	WPA/WPA2/WPA3
	Guest Network	2.4 GHz, 5 GHz
	WPS	True
General
General	Operation Modes	Cellular Router Wi-Fi Router
	Mesh	Cudy Mesh Main
	Mesh Backhaul	Wireless Backhaul Wired Backhaul
	Cellular APN	Band Select (Band Lock) Cellular Mode Select Data Roaming APN Profile Manual APN Profile MBN MTU Value
	Cellular Mode	5G NSA Only 5G SA Only 4G Only 3G Only Auto
	WAN Mode	DHCP Static IP PPPOE L2TP PPTP
	Internet Failover Sequence	WAN Cellular
Network
Network	QoS	Per-User Rate Limiting
	DHCP	Address Reservation DHCP Client List Server
	IP Versions	IPv4/IPv6
	IPv6 Protocols	Relay Dynamic (SLAAC/DHCPv6) Static (Fixed IP) Passthrough 464XLAT MAP-E DS-Lite
	IPTV/VLAN	Bridge Tag VLAN
	TTL Customization	Extend Spoof Custom
	IGMP	IGMP Proxy IGMP Snooping
	Forwarding	Port Forwarding Port Triggering UPnP DMZ
	Firewall	SPI Firewall DoS Protection Block PING
	Application Layer Gateway	IPSec Passthrough L2TP Passthrough PPTP Passthrough FTP Passthrough TFTP Passthrough H323 Passthrough SIP Passthrough RTSP Passthrough
Utilities
Utilities	VPN Server	WireGuard OpenVPN IPsec Zerotier PPTP L2TP
	VPN Client	WireGuard OpenVPN IPsec Zerotier PPTP L2TP
	DNS Options	DNS over TLS Manual DNS Rebind Protection Override Clients' DNS
	DNS over TLS Providers	Cloudflare Google Quad9 Custom
	Wake on LAN	True
	Online Detection	True
Management
Management	Parental Controls	Profiles Settings Offline Time Online Time Pause the Internet Web Filter
	All Devices Management	Wi-Fi Time Schedule MAC Filter IP/MAC Binding
	Per-Devices Management	Internet On/Off VPN On/Off Online Time Schedule Device Rename
	Content Management	Domain Filter IP Filter
System
System	LED Control	True
	Local Control Method	Config Web Page App Control
	Remote Control Method	Config Page via HTTPS App Control TR069/TR098/TR111/TR143/TR181
	Firmware Upgrade	Local Update App (Over the Air) Online Update
	Diagnostic Tools	Diagnosis Ping Traceroute NSLookup System Log
	Languages	English Bengali Catalan Czech German Greek Spanish French Hebrew Croatian Hungarian Italian Japanese Khmer Korean Dutch Norwegian Polish Portuguese Romanian Russian Slovak Swedish Thai Turkish Ukrainian Vietnamese Simplified Chinese Traditional Chinese
	Reliability	Timed Reboot Backup and Restore
Dashboard
Dashboard	Panel	Internet Status Mesh Status Devices Management Cellular Status SMS Send and Receive WAN Status LAN Status Wi-Fi Status VPN Status DHCP Server Status System Version
	Charts	Mesh Topology Cellular Speed Internet Speed Wi-Fi Speed

Actual cellular speeds will vary depending on carrier conditions and environmental factors such as cellular base station location/distance, nearby clients density, building layout, and physical obstacles.
Faktiskā bezvadu datu caurlaides spēja var atšķirties atkarībā no tīkla apstākļiem, klienta ierobežojumiem un vides faktoriem, tostarp ēkas izkārtojuma, šķēršļiem un klienta atrašanās vietas.
